Pipe Rollers

Pipe Rollers

This device is essential for supporting the pipes while they are being welded with the butt fusion machines.

The roller minimizes pipe friction and drag force independently of the jobsite conditions. – ROLLER 355 can sustain pipes up to Ø 355 mm – 14” IPS. Easy to use and light – ROLLER 1000 can sustain pipes from up to 1000 mm – 36” DIPS. The structure is light, so it is easy to carry and can be disassembled and reassembled in a few steps. This feature allows to store up to eight rollers in a single pallet thus improving transportation and logistics.

Another advantage is the misalignment of the rollers in order to move the pipe easily even with the presence of weld beads. Working range from Ø 315 to 1000 mm (10” DISP – 36” DIPS)

Standard Composition

  • Complete roller with tools

Technical Specification

HS Rollers

HIGH STAND ROLLERS, this device is essential for supporting the pipes while they are being
welded with the butt fusion machines. The rollers minimise pipe friction and drag force no
matter which is the construction site condition. Special design for All Terrain / Trailer Line.

Technical Features

HS ROLLERS 250

Working range max: Ø 250 mm (8” DIPS) Overall dimension (W x D x H): 1150 x 500 x 756 mm 45.3” x 19.7” x 29.7” Weight: 26 Kg 57.3 lb Weight capacity: 500 Kg 1.100 lb

HS ROLLERS 335

Working range max: Ø 250 mm (8” DIPS) Overall dimension (W x D x H): 1150 x 500 x 756 mm 45.3” x 19.7” x 29.7” Weight: 26 Kg 57.3 lb Weight capacity: 500 Kg 1.100 lb

HS ROLLERS 360

Working range max: Ø 355 mm (14” IPS)
Overall dimension (W x D x H):
1421 x 600 x 818 mm
55.9” x 23.6” x 32.2”
Weight: 33 Kg 72.8 lb
Weight capacity: 1000 Kg 2.200 lb

HS ROLLERS 630

Working range max: Ø 630 mm (24” DIPS)
Overall dimension (W x D x H):
1766 x 800 x 982 mm
69.5” x 31.5” x 38.6”
Weight: 55 Kg 121.2 lb
Weight capacity: 2000 Kg 4.400 lb

HS ROLLERS 1000

Working range max: Ø 1000 mm (36” DIPS) Weight: 140 Kg 309 lb Weight capacity: 3000 Kg 6.600 lb

HS 1000
